TOA A-1706 PowerMixer (เพาเวอร์มิกเชอร์) TOA A 1706 ราคา 12,000 บาท

หน้าแรก » เครื่องใช้ไฟฟ้า » เครื่องเสียง

TOA A-1706 PowerMixer (เพาเวอร์มิกเชอร์) TOA A 1706 ราคา 12,000 บาท


Specification Power Source AC mains 50/60Hz) Output 60W Power Consumption 150W (rated output), 60W (EN60065) Frequency Response 50 - 20,000Hz ±3dB Distortion Under 2% at 1kHz, rated power Input MIC 1 - 6: -60dB*, 600Ω, electronically-balanced, combined type of XLR-3-31 equivalent and phone jack AUX 1 - 2: -20dB*, 600Ω, electronically-balanced, combined type of XLR-3-31 equivalent and phone jack (Either MIC 5 or AUX 1, and either MIC 6 or AUX 2 selectable) AUX 3 - 4: -20dB*, 10kΩ, unbalanced, RCA pin jack AUX 5: -20dB*, 10kΩ, unbalanced, combined type of XLR-3-31 equivalent and phone jack PWR AMP IN: 0dB*, 600Ω, unbalanced, RCA pin jack An equalizer or other signal processor connectable between LINE OUT and PWR AMP IN terminals) Output REC: 0dB*, 600Ω, unbalanced, RCA pin jack LINE: 0dB*, 600Ω, unbalanced, RCA pin jack SPEAKER SELECTOR: 2 zone, high impedance (100V line/167Ω), individual selector key, M4 screw terminal DIRECT SPEAKER OUT: High impedance (100V line/167Ω),M4 screw terminal Low impedance (4 - 16Ω), M4 screw terminal (Both Low and High impedance terminals cannot be used at the same time.) Phantom Power ON or OFF for each MIC 1 - 6 with switch setting S/N ratio (Band Pass: 20 - 20,000Hz) Over 100dB (Master volume: min) Over 76dB (Master volume: max) Over 60dB (MIC 1 - 4)) Over 53dB (MIC 5, 6) Over 76dB (AUX 1 - 5) Tone Control Bass: ±10dB at 100Hz, Treble: ±10dB at 10kHz Control Input REMOTE VOLUME: M3 screw terminal POWER REMOTE: No-voltage make contact input, open voltage: 24V DC (when the unit's power is OFF), short-circuit: under 10mA, M3 screw terminal Indicator 5 point LED output level meter, Power indicator LED, Zone indicator LED Operating Temperature -10ºC - +40ºC Finish Panel: ABS resin, black, hair line Case: Steel plate, black Dimensions 420 (W) x 107.7 (H) x 367 (D)mm Weight 9.3kg Accessory Power cord x 1, Terminal block cover x 1, Terminal block cover mounting screw x 2 Option Rack mounting bracket: MB-25B, Volume control cover: YA-920. Note* Note: Distance between barriers on the above screw terminals; M3 = 7mm, M4 = 9mm * 0dB = 1V





ราคา: 12,000ต้องการ: ขาย
ติดต่อ: นายสุพจน์ สุวรรณสุตอีเมล์:
สภาพ: ใหม่ จังหวัด: ปทุมธานี
โทรศัพย์: 0897762636IP Address: 58.11.209.xx
มือถือ: 0897762636
ที่อยู่: 343 ซอยรังสิต-นครนายก 27 ซ.1 ต.ประชาธิปัตย์อ.ธัญบุรี

คำค้น:  1706 | (เพาเวอร์มิกเชอร์) | powermixer | a1706 | a-1706 |
